SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications

Zhengzhou Timeway Machine Tool Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers

    Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers
    • Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers
    • Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers
    • Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers
    • Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers
    • Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers
    • Buy cheap SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications from wholesalers

    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications

    Ask Lasest Price
    Brand Name : TIMEWAY
    Certification : CE ISO
    Supply Ability : 150 Set/Sets per Month
    Price : $18,000.00/sets 1-2 sets
    • Product Details
    • Company Profile

    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications

    Products Description
    SG-4080AH
    Saddle Moving Type Surface Grinder:
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    Specification
    Unit
    SG-4080AH
    SG-4080AHR
    SG-4080AHD
    Table size
    mm
    406x813
    Electro magnetic chuck size
    mm
    400x800
    Distance from spindle to table
    mm
    580
    Table cross travel
    mm
    450
    Table longitudinal travel
    mm
    910
    Loading capacity (include chuck)
    kg
    500
    Longitudinal feed speed
    m/min
    5-25
    Table cross intermittent feed rate
    mm/str
    0.1-8
    Table cross rapid feed speed
    mm/min
    990
    Table cross feed of handwheel
    mm/gra
    0.02
    Wheelhead vertical intermittent feed rate
    mm/str
    AH: -;
    AHR: -;
    AHD: 0.005-0.5;
    Wheelhead vertical rapid feed speed
    mm/min
    AH: -;
    AHR: 650;
    AHD: 480;
    Wheelhead vertical feed of handwheel
    mm/gra
    0.005
    Spindle speed (50/60HZ)
    rpm
    1450/1750
    Grinding wheel size
    mm
    350x40x127
    Main motor power
    kw
    4
    Machine dimensions (LxWxH)
    cm
    360x240x190
    Package dimensions (LxWxH)
    cm
    285x227x221
    Machine weight
    kg
    3400
    Positive Comments From Customers
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    Shipping
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    Exhibitions
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications

    TIMEWAY at EMO Hannover

    TIMEWAY machine participates in the EMO Hannover exhibition every time, which is Europe's leading machine tool and metal processing technology exhibition. At the exhibition, TIMEWAY machine demonstrated its advanced machine tools and processing technology, as well as comprehensive solutions for different industries and application fields. These solutions include precision machining and production of high-quality metal parts for the automotive, aerospace, energy, and other sectors.
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications

    TIMEWAY at CIMT

    CIMT is held in China, the hometown of TIMEWAY machine, so TIMEWAY machine will participate in the CIMT exhibition every time. This is the China International Machine Tool Exhibition and one of the largest machine tool exhibitions in Asia. At the exhibition, TIMEWAY displayed its diversified machine tool products, including CNC machine tools, machining centers, gear processing machine tools, precision measuring equipment, etc.
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications

    TIMEWAY at Metalloobrabotka

    TIMEWAY machine participated in the Metalloobrabotka exhibition held in Moscow, which is a professional exhibition for the metal processing and machine tool industry in Russia and surrounding areas. At the exhibition, TIMEWAY machine booth attracted the attention of many exhibitors and industry experts. The company's professional team had in-depth exchanges with exhibitors and visitors from Russia and other countries and regions, sharing valuable experience and the latest industry trends. In addition, TIMEWAY machine has also participated in exhibitions in many countries and regions.
    Company Introduction
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    Factory Display:
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    Text Introduction:
    SG-4080AH High Precision Surface Grinding Machine Suitable for Various Applications
    Company Profile:
    Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
    Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
    FAQ
    Q: Why choose TIMEWAY MACHINE?
    A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
